Select tapes may be printed using several varieties of printing and processing techniques. Splices and connections may be insulated utilizing pressure-sensitive tape. Inter-layer insulation may be held in place or may be entirely comprised of an IPG tape. The final outer coil wrap or end cap insulation may be designed and applied using any one of several IPG tapes. We have your pressure-sensitive tape solution for almost every related application.
Products
Page 1 of 2
-
4118
Silicone 1 Mil Kapton® Polyimide Tape
Kapton® polyimide backing and silicone adhesive offers outstanding thermal resistance and excellent electrical insulating properties. This tape is used where toughness, puncture resistance, extreme resistance to heat, and flame retardance are required. Operating temperature range is -60°C (-76°F) to +260°C (500°F).
View Product -
4240
PET FILM / BIDIRECTIONAL GLASS ELECTRICAL TAPE ‘PROVISIONAL’
Moderate strength glass scrim and conformable PET film coated with an aggressive acrylic adhesive for a variety of heavy duty insulating, banding and holding applications. The 1.0 mil (25μ) polyester film provides puncture, edge tear and abrasion resistance. 4240 is specially designed and intended for use in oil-filled transformers. Once...
View Product -
4428
Polyimide Film Electrical Tape
Polyimide backing and silicone adhesive offers outstanding thermal resistance and excellent electrical insulating properties. This tape is used where toughness, puncture resistance, extreme resistance to heat, and flame retardance are required. Operating temperature range is -60°C (-76°F) to +260°C (500°F).
View Product -
4429
2 Mil Silicone Polyimide Tape
Extra strength polyimide backing and silicone adhesive offers outstanding thermal resistance and excellent electrical insulating properties. This tape is used where toughness, puncture resistance, extreme resistance to heat, and flame retardance are required.
View Product -
4560
7 Mil Rubber Thermoset Acetate Cloth Tape
This printable tape, with acetate cloth backing and a thermosetting rubber adhesive system offers high adhesion, conformability, and excellent insulating properties.
View Product -
4564
Non-Woven Polyester Electrical Tape
4564 utilizes porous non-woven polyester backing with a zone coated acrylic adhesive. The porous area without adhesive allows the impregnating fluids to pass through, avoiding air entrapment. The impregnated and cured tape provides a high insulating barrier. Ideal for coil wrapping, tabbing, anchoring, and for affixing glass fabrics during injection...
View Product -
4616
Glass Cloth Electrical Tape
MIL-T-4053 B Along with its high adhesion and resistance to tearing, this tape offers a rubber thermosetting adhesive system that gives it excellent solvent resistance.
View Product -
4617
Glass Cloth Electrical Tape
CID AA-59770-4, MIL-I-15126F 4617 has an inert, temperature resistant, high tensile strength backing with an acrylic adhesive. Acrylic thermosetting adhesive system provides outstanding resistance to oils, solvents and chemicals. Its excellent conformability remains flexible after cure. This tape is ideal for inter-layer insulation, coil outer wraps, tie-downs, lead insulation and...
View Product -
4618
7 Mil Silicone Glass Cloth Tape
Inert, high strength backing and heat resistant silicone adhesive for high temperature applications. This tape resists edge fraying and rotting and is flexible and varnish absorbent. Used in applications where solvent resistance, flame retardance and abrasion resistance is required.
View Product -
51245
Polyester Film / Polyester Non-Woven Electrical Tape
The combination of polyester film and polyester non-woven materials can be used on a wide variety of electrical applications. Multi-purpose tape for applications which require a combination of tear and puncture resistance, high tensile strength with elongation and excellent dielectric strength.
View Product -
51337
Flatback Paper / Acrylic Adhesive Electrical Tape
Puncture and abrasion resistant flat-back paper backing and aggressive acrylic adhesive make this a low cost all-purpose electrical insulating tape. Acrylic thermosetting adhesive system also provides excellent solvent resistance. pH Neutral.
View Product -
51579
1 Mil Acrylic Polyimide Film Electrical Tape
Kapton® polyimide backing and high tack acrylic adhesive offers excellent chemical and thermal resistance with excellent electrical insulating properties. This tape is used where toughness and puncture resistance are required.
View Product
